Heating element NEX1

The heating element features Bluetooth, Wi-Fi, an 868 MHz radio communication mode and a built-in room temperature sensor with open window/door detection.

Select variant

Specifications

  • max.recommended electric heating element 200.00 W

Color availability

All prices are exclusive of VAT.

White - gloss
289,68 €
Metallic silver - gloss
289,68 €
Black - semi-gloss
289,68 €
excl. VAT

Electric operation

Heating elements allow the radiator to be used in electric or combined mode.

Independent heating

The heating element extends the use of the radiator even outside the operation of the central heating system.

Various designs

Heating elements are available in various variants to match the selected radiator.

Detailed description

Comprehensive description of the product and its functions.

The heating element features Bluetooth, Wi-Fi, an 868 MHz radio communication mode and a built-in room temperature sensor with open window/door detection.

The heating element can be controlled remotely via the Smart Life / Tuya Smart mobile app. If the electric heating element has a stable Wi-Fi connection, it can be controlled from anywhere in the world — all you need is internet access.

An electric radiator equipped with the NEX heating element meets the requirements of the Eco Design directive.

FEATURES

  • Weekly plan — option to set the radiator temperature or room temperature
  • Room temperature measurement / heating function stop when a window or door is opened
  • TURBO timer — the electric heating element keeps the set temperature for up to 4 hours, then returns to the previously set temperature
  • START-STOP timer — the electric heating element keeps the set temperature for up to 4 hours, then switches off
  • Option to choose heating priority (radiator / room)
  • Radiator temperature control in the range 30–60 °C (from the app with 1 °C precision)
  • Room temperature control in the range 17–24 °C (from the app with 0.1 °C precision)
  • If the room temperature sensor shows a different reading from the actual temperature due to the device's position, the reading can be corrected in the mobile app. The correction can be +4 °C to -4 °C.
  • Overview of the cost of consumed energy — based on the entered data, the app calculates the operating cost of the heating element
  • PARENTAL CONTROL function — blocking the buttons on the heating element via the app
  • Control rotation 0° – 330°
  • ANTIFREEZE function — protection against freezing of the medium in the radiator
  • Two-stage overheating protection
  • Low energy consumption in standby mode (Ultra-Low-Power)
  • Intelligent operation control — microprocessor control
  • Visualization in colour LED technology

Downloads

Detailed parameters.

  • Mounting instruction pdf 2 MB
  • Application Settings pdf 3 MB

Most common general questions

What is the difference between a radiator and an electric dryer?

A radiator is primarily designed for space heating and can be connected to a hot water system, electricity, or combined operation. An electric dryer is intended mainly for convenient drying and warming of towels, without the need for connection to a heating system.

How do I know what type of connection I need?

The type of connection depends on the prepared distribution lines and the specific radiator model. Before ordering, we recommend checking the technical drawings and consulting the solution with a heating engineer or designer.

How do I know if the radiator will heat my bathroom?

It is necessary to know the heat loss of the room or at least its size, layout, and insulation level. An accurate calculation should be performed by a designer or heating expert.

What warranty do you provide on your products?

We provide a 5-year warranty on PMH bathroom radiators. Electric dryers, heating elements, valves, and accessories are covered by a 2-year warranty. The warranty covers manufacturing defects and leaks, provided professional installation and correct use of the product according to the manufacturer's recommendations.

Do you provide service?

For PMH products, we provide technical support, complaint resolution, and assistance with spare parts. However, installation and professional service interventions are carried out by a qualified plumber, heating engineer, or electrician.
